SPARTNA SPR-902 Coating Thickness Tester

SpartnaSKU: SPR-902
filler

Price:
Sale priceAED. 650.00
Stock:
Sold out

Description

The SPARTNA SPR-902 is a versatile coating thickness tester designed for measuring temperature, humidity, dew point temperature, and coating thickness ranging from 0 to 2000 μm. It is suitable for various applications, including non-magnetic coatings on steel and insulating coatings on non-ferrous metals.

  • Measures non-magnetic coatings (e.g., paint, zinc) on steel.
  • Measures insulating coatings (e.g., paint) on non-ferrous metals.
  • Measures non-ferrous metal coatings on insulating substrates.
  • 2.4-inch TFT color LCD display.
  • Temperature, humidity, and dew point temperature measurement.
  • Auto-rotatable screen: 0°, 90°, 180°, 270°.
  • Stability test and continuous test modes.
  • Settable auto power-off time.
Specification Details
Working Principle Magnetic Induction / Eddy Current Principle
Measuring Range 0 ~ 2000 µm
Guaranteed Tolerance (of Reading) (±2% + 2) µm
Repeatability (±1% + 1) µm
Low Range Precision 0.1 µm
Minimum Curvature Radius

1.5 mm (magnetic)
3 mm (non-magnetic)

Diameter of Minimum Area 7 mm (magnetic)
5 mm (non-magnetic)
Basic Critical Thickness 0.5 mm (magnetic)
0.3 mm (non-magnetic)
Temperature Range 0 to 50 °C / 32 to 122 °F
Basic Accuracy (Temperature) ±1 °C / 1.8 °F
Humidity Range 0 to 100%
Basic Accuracy (Humidity) ±3%
